An Open Source Library to record/log your application’s runtime behavior to a persistent medium.

Description

Let’s first understand why we need to use logging.Whether you are a fresh developer or have years of experience writing code, you probably know the concept of logging. Small pieces of text, written to the console, a file, a database, you name it, which will track what your software is doing and help you debug errors after they happen.

Log levels

Log messages written using log4net must be set to any one of the following:

1. Debug – informational events that are most useful to debug an application.
2. Info – logs informational messages
3. Warn – designates potentially harmful situations.
4. Error – designates error events that might still allow the application to continue running.
5. Fatal – events that lead the application to abort.

Where does the logging information go? Well, logging information goes to what is called an Appender. An appender is basically a destination that the logging information will go to.Examples of appenders are the console, a file, a database, an API call, etc.

Integrate Log4net from Scratch

1. Add the log4net Package
2. Specify appender web.config file

<log4net>
    <appender name="LogFileAppender" type="log4net.Appender.FileAppender">
      <param name="File" value="log.txt" />
      <param name="AppendToFile" value="true" />
      <layout type="log4net.Layout.PatternLayout">
        <param name="Header" value="[Header]rn" />
        <param name="Footer" value="[Footer]rn" />
        <param name="ConversionPattern" value="%d [%t] %-5p %c %m%n" />
      </layout>
    </appender>
    <root>
      <level value="INFO" />
      <appender-ref ref="LogFileAppender" />
    </root>
  </log4net>

3. Add below statement to AesemblyInfo.cs

[assembly: log4net.Config.XmlConfigurator(Watch = true)]

4. Tell log4net to Load Config
5. Log something!

class Program
    {
        static void Main(string[] args)
        {
            ILog log = LogManager.GetLogger("mylog");
            log.Debug("This is a debug message");
            log.Info("This is an information message");
            log.Warn("This is a warning message");
            log.Error("This is an error message");
            log.Fatal("This is a fatal message");
            try
            {
                throw new Exception();
                // Something dangerous!
            }
            catch (Exception e)
            {
                log.Error("An error happened", e);
            }
        }

Appenders

It specifies where the information will be logged, how it will be logged, and under what circumstances the information will be logged. While each appender has different parameters based upon where the data will be going, there are some common elements.

<appender name="ConsoleAppender" type="log4net.Appender.ConsoleAppender">

Layout

This will allow you to specify how you want your data written to the data repository. If you specify the pattern layout type, you will need a sub-tag that specifies a conversion pattern

<layout type="log4net.Layout.PatternLayout">
      <conversionPattern value="%date [%thread] %-5level %logger [%ndc]
    - %message%newline"/>
</layout>

Conversion Patterns

Conversion pattern entry is used for the pattern layout to tell the appender how to store the information.

There are many types of appenders available with log4net. You can choose as per your requirement. Below are commonly user appenders:

CREATE TABLE [dbo].[Log](
  [Id] [int] IDENTITY(1,1) NOT NULL,
  [Date] [datetime] NOT NULL,
  [Thread] [varchar](255) NOT NULL,
  [Level] [varchar](50) NOT NULL,
  [Logger] [varchar](255) NOT NULL,
  [Message] [varchar](4000) NOT NULL,
  [Exception] [varchar](2000) NULL
) ON [PRIMARY]

Demo: Refer Link
